Plastic & Rubber Odor Control Biofilter

The BIO Series Biofilter is specially designed for plastic/rubber industry, combining “biofiltration+chemical oxidation” to remove H₂S, BTEX, NMHC with ≥95% efficiency. Complies with EPA Method 25A and EU Industrial Emissions Directive.

Application

  • ✔ Rubber Curing: H₂S & mercaptans treatment
  • ✔ Plastic Extrusion: NMHC abatement
  • ✔ Mixing Areas: Benzene series & dust control
  • ✔ Waste Processing: Pyrolysis gas deodorization

Working Princple

  1. Pre-treatment
  • PP ducting with cyclone + quencher (temperature≤40℃)
  1. Bio-chemical Process
  • 3-stage treatment:
    • Stage 1: Alkaline scrubber (H₂S removal>90%)
    • Stage 2: Biofilter with specialized microbes (BTEX degradation)
    • Stage 3: UV-photocatalytic oxidation (for refractory VOCs)
  1. Smart Control
  • Real-time TVOC monitoring with auto-dosing system
  1. Final Emission
  • Meets EPA Subpart WW/NNNNN standards

Features

  • 🔸 Customized Design
  • Shock load resistant (500-5000mg/m³ fluctuation)
  • 🔸 High Efficiency
  • Microbial consortia adapt to pH 3-9 & 15-50℃
  • 🔸 Safety Assurance
  • Anti-static construction (surface resistance<10⁹Ω)
  • 🔸 Cost-effective
  • Operational cost<$0.1/m³, 70% saving vs RTO
