Gas Collection
FRP ducts (velocity 1.2-1.8m/s) deliver gases to scrubber
Pre-treatment
Water scrubber removes particulates (＞5μm, 85% efficiency)
Humidity adjusted to 90-95% RH
Biofiltration
3-layer media:
Lava rock (porosity≥40%)
Bamboo-activated carbon composite (iodine value≥800mg/g)
Slow-release nutrient layer
Smart Control
PLC adjusts spraying frequency (2-5 cycles/hour)
Auto pH balancing (6.5-7.5)
Full PP construction (thickness≥12mm), pH 2-12 resistant
✅ Load Adaptability
Microbial community adapts to 50-3000mg/m³ in 48h
✅ Energy Saving
Operational cost＜$0.08/m³ (65% saving vs chemical scrubbers)
✅ IoT Monitoring
Real-time H₂S/NH₃ tracking via web-based dashboard
The BIO Series GMP Adsorption System is engineered for Pharmaceutical VOC Adsorber, featuring "medical-grade carbon+hot N₂ regeneration" to achieve 99.5%
The BIO Series Lab Adsorber (Activated Carbon Adsorption) is designed for research facilities, featuring "high-iodine carbon+HEPA" technology to remove 99%
The BIO Series Acid-Resistant Adsorber Chemical-Resistant Carbon Filter is engineered for metal pickling operations, utilizing "chemically-modified activated carbon+alkaline scrubber" to
